Custom-Engineered
Measurement Systems
Whether it’s automating a physical quality check currently done by a human operator, upgrading a legacy inline system, or rescuing a failed automation effort - we’ve been in your shoes. With decades of combined experience in manufacturing and solutions development, we know that reliable measurement automation is about more than just wiring a sensor.
The Process: Lean Engineering & The DMAIC Approach
With a deep background in Lean manufacturing and automation engineering, we never start by prescribing a hardware catalog. We follow a rigorous DMAIC framework to ensure we are solving the root cause of your bottleneck, not just treating a symptom.
- Define (The Financial Problem): We accurately define the problem and the financial impact of the current defect or bottleneck. We align with your team on the vision and target ROI.
- Measure (The Current State): We dive into the process, measuring ambient environmental challenges, lighting variability, and the needs of all relevant operators on the floor.
- Analyze (The Conceptual Solution): We analyze the data to determine the exact measurement science required. We provide a transparent conceptual solution and a fixed-price budgetary value for the architecture.
- Improve (Design & Execution): We design the solution and ensure seamless physical automation deployment alongside our trusted hardware and integration partners, communicating progress from kickoff to commissioning.
- Control (Steady-State Support): Once the new process is capable and in control, we partner with you on the next most important challenge in your operation.
Our Measurement Automation Capabilities
We don't just specify sensors; we engineer the entire automated ecosystem required to make measurement work flawlessly in harsh industrial manufacturing environments.
Multi-Instrument Hardware Systems
As a hardware-agnostic engineering firm, we specialize in architecting turnkey automated cells that fuse multiple sensor types, including:
- Machine Vision & Smart Cameras: Engineered with custom lighting and optical filtering to eliminate ambient interference.
- Laser Profilers & Displacement Sensors: For high-speed, 2D/3D dimensional verification.
- Optical Gauging Systems: For complex surface defects and finish qualities.
- Process Instrumentation: For real-time flow, temperature, and fluid/solid metrics.
Part Presentation & Motion Control
A measurement is useless if the part is not presented perfectly every single time. We design the architecture for robust mechanical automation. From specifying custom fixturing concepts to engineering the logic for multi-axis motion control, we ensure repeatability at high speeds.
Inline Reject & Actuation Mechanisms
Finding a bad part is only half the battle. We engineer the parameters and logic for high-speed actuators and PLC-driven reject automation to physically sort out defects without slowing down your production line.
Environmental Durability
Factory floors have dust, oil, variable lighting, and heavy vibration. We specify the appropriate IP-rated and NEMA enclosures, custom brackets, and protective housings required so your delicate instruments survive the reality of your manufacturing environment.
Beyond the physical hardware, we engineer the custom software and data translation layers required to turn raw sensor data into actionable plant-floor intelligence.
Real-World Measurement & Inspection Architecture
We figure out the science; we design the automation architecture. Examples of our engineering include:
Deep Learning & AI Architecture
-
AI for Quality Inspection: Designing neural network and AI-driven vision architectures to detect unpredictable, organic defects on complex surfaces where traditional automation fails.
-
Complex Assembly Verification: Engineering AI models to verify multi-component assemblies (e.g., wire routing, connector seating) where lighting variations and background clutter confuse traditional tools.
2D Machine Vision & Surface Defect Detection
-
Continuous Solder Quality Verification: Developing the measurement science for multi-camera arrays and SQL-backed web servers to achieve 100% inline inspection of microscopic solder joints.
-
High-Speed OCR & Traceability: Specifying the high-contrast optics and lighting required for automated barcode and OCR reading on challenging packaging surfaces.
3D Profiling & Laser Scanning
-
High-Speed Web Inspection (Flooring Industry): Engineering continuous 3D profile and surface measurement strategies to monitor shape tolerance and board dimensions on high-throughput continuous webs.
-
Automated Weld Inspection: Designing 3D profiling architectures to continuously measure weld bead geometry, undercut, and porosity to ensure strict structural compliance.
Vision-Guided Robotics (VGR) & Motion
-
Dynamic Robotic Guidance: Architecting the 3D vision-to-robot coordinate calibration required for collaborative or industrial robot automation in pick-and-place or bin picking.
Non-Optical Process & Leak Testing
-
Inline Pressure & Vacuum Testing: Architecting custom pneumatic and vacuum decay testing parameters to identify micro-leaks in battery cell covers, complete with statistical operator feedback
Frequently Asked Questions
How does "Measurement Science" differ from standard automation integration?
Standard automation integrators are experts in PLC programming and ladder logic, often treating cameras and lasers as "pass/fail" black boxes. We are architects of the measurement science. Before we ever write a line of control code, we engineer the underlying physics: the wavelength of the lighting, the optical filtration, and the triangulation geometry of the lasers required to ensure your data is repeatable and statistically valid.
Can AI-driven vision automation solve for "unpredictable" defect detection?
Yes, but not with standard rule-based tools. When background noise or organic part variations (like wood grain) confuse traditional vision, we design Deep Learning and Neural Network architectures. This allows the system to "learn" the acceptable range of variability, enabling the automation of inspections that standard system integrators cannot stabilize.
What are the technical requirements for 3D measurement on a continuous moving line?
Continuous web inspection (flooring, film, or metal) requires more than just a fast camera. It requires synchronized 3D laser line-scanning and precise spatial-temporal alignment. Automadex architects the logic that compensates for web-wander and vibration, ensuring the data captured at high speeds has the same integrity as a static lab measurement.
How do you ensure accuracy in Vision-Guided Robotics (VGR) applications?
A robotic arm is only as accurate as its "eyes." Automadex provides the 3D vision-to-robot coordinate calibration architecture, handling the complex 6-degree-of-freedom (6DoF) math required to ensure the robot "sees" exactly where the part is in 3D space, regardless of orientation.
Does your measurement engineering extend to non-optical process testing?
Absolutely. True measurement specialists understand that not every answer is found with a camera. Among other things, Automadex designs solutions for Inline Vacuum Decay and Pressure Differential testing, engineering the physics of the "test circuit" to ensure your leak measurements meet strict NIST-traceable or regulatory standards.
Your Partner in Continuous Improvement
What physical bottleneck is slowing down your automation today?
